No additional description available.
Request Quote
Availability: 0 In Stock
No additional description available.
Request Quote
Availability: 0 In Stock
The BRCS01C is an advanced AC/DC residual current sensor designed for electric vehicle (EV) chargers, ensuring compliance with the residual current protection requirements outlined in IEC 61851-1 for Mode-3 EV charging. It features two separate fault signal outputs: one pin for detecting Type A 30 mA AC and 6 mA DC residual currents, and another pin dedicated exclusively to detecting 6 mA DC residual current. This dual-output configuration makes the BRCS01C suitable for built-in RDC-PD, Type-A mRCD+RDC-MD, and RDC-MD applications in AC EV chargers. The BRCS01C is available in two interface versions: 12V DC and 5V DC. The 12V version includes an integrated MOSFET with a maximum switching current of 500 mA, enabling direct coupling to relays or contactors within EV chargers. The 5V version offers superior protection against transients, ensuring stable performance even in dynamic environments.
Request Quote
Availability: 0 In Stock
No additional description available.
Request Quote
Availability: 0 In Stock
No additional description available.
Request Quote
Availability: 0 In Stock
No additional description available.
Request Quote
Availability: 0 In Stock
No additional description available.
Request Quote
Availability: 0 In Stock
The BRCS03C is a high-performance AC/DC residual current sensor designed for integration into electric vehicle (EV) charging stations. It features two independent fault signal outputs: one pin for DC fault signal detection and another for combined AC & DC fault signals. This dual-output configuration makes the sensor ideal for RDC-DD applications, functioning as an RDC-MD (Residual Direct Current Monitoring Device, DC 6mA, IEC 62955) or an RDC-PD (Type A 30mA and DC 6mA, IEC 61008-1/IEC 60947-2 + IEC 62955) in Mode-3 AC chargers.
Request Quote
Availability: 0 In Stock
The BRCS03C is a high-performance AC/DC residual current sensor designed for integration into electric vehicle (EV) charging stations. It features two independent fault signal outputs: one pin for DC fault signal detection and another for combined AC & DC fault signals. This dual-output configuration makes the sensor ideal for RDC-DD applications, functioning as an RDC-MD (Residual Direct Current Monitoring Device, DC 6mA, IEC 62955) or an RDC-PD (Type A 30mA and DC 6mA, IEC 61008-1/IEC 60947-2 + IEC 62955) in Mode-3 AC chargers.
Request Quote
Availability: 0 In Stock
The BRCS03C is a high-performance AC/DC residual current sensor designed for integration into electric vehicle (EV) charging stations. It features two independent fault signal outputs: one pin for DC fault signal detection and another for combined AC & DC fault signals. This dual-output configuration makes the sensor ideal for RDC-DD applications, functioning as an RDC-MD (Residual Direct Current Monitoring Device, DC 6mA, IEC 62955) or an RDC-PD (Type A 30mA and DC 6mA, IEC 61008-1/IEC 60947-2 + IEC 62955) in Mode-3 AC chargers.
Request Quote
Availability: 0 In Stock
The BRCS03X is a high-performance AC/DC residual current sensor featuring two independent fault signal outputs: one pin for Type A 30 mA & DC 6 mA leakage current detection and another pin exclusively for DC 6 mA leakage current detection. This dual-output design makes the sensor suitable for built-in RCD / RDC-DD applications in AC charging stations, ensuring compliance with IEC 61851-1 and IEC 60364-7-722 standards.
Request Quote
Availability: 0 In Stock
The BRCS03X is a high-performance AC/DC residual current sensor featuring two independent fault signal outputs: one pin for Type A 30 mA & DC 6 mA leakage current detection and another pin exclusively for DC 6 mA leakage current detection. This dual-output design makes the sensor suitable for built-in RCD / RDC-DD applications in AC charging stations, ensuring compliance with IEC 61851-1 and IEC 60364-7-722 standards.
Request Quote
